3 1/4″ M-950 Series Fixed
With a deeper frame, numerous available installation systems, and a variety of mulling and stacking options, the M-950 is our most versatile, high performance series.
Jump to:2 11/16″ M-85 Fixed 2 3/8″ 4500 Fixed
- 3 1/4″ frame depth
- 1″ sealed IGU with optional 1 1/4″ or 2″ IGU available
- Standard rating: AW40
- Optional ratings: AW80, AW90
- .062 typical wall thickness, aluminum alloy 6063-T6
- Interior and exterior accessory channels
- Impact-resistant model passed Large Missile D Zone 3 impact testing
All Wojan windows and doors feature pour and debridge polyurethane thermal breaks and come with a 10-year warranty against failure of the polymer.LEARN MORE
STANDARD FINISHES AVAILABLE
Bronze 2603
White 2603
Bronze 2605
White 2605
Black 2605
Clear Anodized
Bronze Anodized
Non-standard finishes are available with a minimum order.
PRODUCT PERFORMANCE DETAILS
| RATING | STRUCTURAL/ WATER/AIR TEST SIZE |
AIR INFILTRATION (cfm/sq ft) |
WATER RESISTANCE (psf) |
DEFLECTION (psf) |
STRUCTURAL* (psf) |
|---|---|---|---|---|---|
| AW40 | 60″W x 99″H | < 0.01 @ 6.2 psf | 8.15 | 40 | 60 |
| optional: AW80^ | 60″W x 99″H | < 0.01 @ 6.2 psf | 12.11 | 80 | 120 |
| optional: AW90^ | 60″W x 99″H | < 0.01 @ 1.57 psf | 12.11 | 90 | 135 |
| Fixed/Fixed: AW 40 | 60″W x 99″H | < 0.01 @ 6.2 psf | 8.15 | 40 | 60 |
| Fixed/Fixed, optional: AW75^ | 60″W x 99″H | < 0.01 @ 6.2 psf | 12.11 | 75 | 112.5 |
^ Many window ratings can be increased by downsizing the window and determining maximum performance through testing. Contact your local Wojan Sales Representative or our office for details.
* This is an intentional overload aspect to window performance testing and should not be used in lieu of the window DP (Design Pressure) when evaluating a product for a specific project or use.
Fixed and Fixed/Fixed models are approved by the Florida Building Commission. See details here.
CAD DRAWINGS
| CONFIGURATION | DESCRIPTION | DWG | |
|---|---|---|---|
 |
Fixed Standard |  |
 |
 |
Fixed-Fixed Standard | |
|
 |
Fixed-Fixed-Fixed Standard | |
|
 |
Fixed over Fixed Standard | |
|
 |
Fixed over Fixed over Fixed Standard | |
|
Contact us for other configurations.
2 11/16″ M-85 Series Fixed
Favored for hospitality projects, the M-85 Series is the quintessential no-nonsense performer in reliable, cost-effective windows. Also ideal for low to mid-rise commercial structures such as mixed-use apartments and condominiums where more cost-effective aluminum windows are preferred.
- 2 11/16″ frame depth
- 1″ sealed IGU
- Standard ratings: CW30, CW50
- Optional ratings: CW65 (additional options with other configurations)
- .050 typical wall thickness, aluminum alloy 6063-T6
- Impact-resistant model passed Large Missile D Zone 3 impact testing
- Fixed over louver configuration is factory stacked in one master frame, and available with all the same features and options as the standard model
All Wojan windows and doors feature pour and debridge polyurethane thermal breaks and come with a 10-year warranty against failure of the polymer.LEARN MORE
STANDARD FINISHES AVAILABLE
Bronze 2603
White 2603
Bronze 2605
White 2605
Black 2605
Clear Anodized
Bronze Anodized
Non-standard finishes are available with a minimum order.
PRODUCT PERFORMANCE DETAILS
| RATING | STRUCTURAL/ WATER/AIR TEST SIZE |
AIR INFILTRATION (cfm/sq ft) |
WATER RESISTANCE (psf) |
DEFLECTION (psf) |
STRUCTURAL* (psf) |
|---|---|---|---|---|---|
| CW30 | 60″W x 72″H | < 0.01 @ 1.57 psf | 4.60 | 30 | 45 |
| CW50 | 60″W x 72″H | < 0.01 @ 1.6 psf | 7.52 | 50 | 75 |
| optional: CW65^ | 60″W x 72″H | < 0.01 @ 1.57 psf | 9.82 | 65 | 97.5 |
| Fixed over Louver: CW30 | 60″W x 72″H | < 0.01 @ 1.57 psf | 4.60 | 30 | 45 |
| Fixed over Louver, optional: CW50^ | 60″W x 72″H | < 0.01 @ 1.6 psf | 7.52 | 50 | 75 |
| Fixed over Louver, optional: CW65^ | 60″W x 72″H | < 0.01 @ 1.57 psf | 9.82 | 65 | 97.5 |
| Fixed-Fixed: CW40 | 60″W x 78″H | < 0.01 @ 6.2 psf | 6.06 | 40 | 60 |
| Fixed-Fixed, optional: CW45^ | 60″W x 78″H | < 0.01 @ 6.2 psf | 6.90 | 45 | 67.5 |
| Fixed-Fixed, optional: C50^ | 60″W x 78″H | < 0.01 @ 6.2 psf | 7.52 | 50 | 75 |
| Fixed-Fixed, optional: C80^ | 60″W x 78″H | < 0.01 @ 6.2 psf | 12.11 | 80 | 120 |
^ Many window ratings can be increased by downsizing the window and determining maximum performance through testing. Contact your local Wojan Sales Representative or our office for details.
* This is an intentional overload aspect to window performance testing and should not be used in lieu of the window DP (Design Pressure) when evaluating a product for a specific project or use.
Fixed and Fixed-Fixed models are approved by the Florida Building Commission. See details here.
CAD DRAWINGS
| CONFIGURATION | DESCRIPTION | DWG | |
|---|---|---|---|
 |
Fixed Standard | |
|
 |
Fixed over Fixed Standard | |
|
 |
Fixed over Louver Subsill | |
|
Contact us for other configurations.
2 3/8″ 4500 Series Fixed
Our heavy-duty 4500/4600 Series is a rugged, durable, and affordable option in projected windows. The unique integral mulling/stacking system provides a virtually unlimited selection of multi-window configurations within a single master frame.
STANDARD FINISHES AVAILABLE
Bronze 2603
White 2603
Bronze 2605
White 2605
Black 2605
Clear Anodized
Bronze Anodized
Non-standard finishes are available with a minimum order.
PRODUCT PERFORMANCE DETAILS
| RATING | STRUCTURAL/ WATER/AIR TEST SIZE |
AIR INFILTRATION (cfm/sq ft) |
WATER RESISTANCE (psf) |
DEFLECTION (psf) |
STRUCTURAL* (psf) |
|---|---|---|---|---|---|
| AW40 | 60″W x 99″H | < 0.01 @ 6.27 psf | 8.15 | 40 | 60 |
| optional: AW100^ | 60″W x 99″H | < 0.01 @ 6.27 psf | 12.11 | 100 | 150 |
| with receptor: AW55 | 61″W x 94″H | < 0.01 @ 6.2 psf | 11.07 | 55 | 82.5 |
| with receptor, optional: AW80^ | 72″W x 84″H | 0.03 @ 6.2 psf | 12.11 | 80 | 120 |
| Fixed-Fixed with receptor: AW70 | 46″W x 74″H | 0.03 @ 6.2 psf | 12.11 | 70 | 105 |
^ Many window ratings can be increased by downsizing the window and determining maximum performance through testing. Contact your local Wojan Sales Representative or our office for details.
* This is an intentional overload aspect to window performance testing and should not be used in lieu of the window DP (Design Pressure) when evaluating a product for a specific project or use.
CAD DRAWINGS
| CONFIGURATION | DESCRIPTION | DWG | |
|---|---|---|---|
 |
Fixed Standard | |
|
 |
Fixed-Fixed Standard | |
|
 |
Fixed-Fixed-Fixed Standard | |
|
 |
Fixed over Fixed Standard | |
|
 |
Fixed over Fixed over Fixed Standard | |
|
Contact us for other configurations.
4500/4600 Series with Integral Nail Fin
The integral nail fin provides a complete exterior weather-barrier as part of the fixed window frame.
- Integral to all 4 sides of the exterior fixed window frame.
- Not an “add-on” piece; no seam caulking required.
- Less costly because there is no applied nail fin needed.
- Reduces the risk and chance of exterior water penetration.
- Installation is simple. Seal behind the nail fin, butter the corners, and fasten through the nail fin.
- Ability to connect with other Wojan nail fin products. Factory applied or field applied.
- Available on all 4500 and 4600 Series projected and fixed products.
All master frames feature pour and debridge polyurethane thermal breaks with a 10-year warranty against failure of the polymer. This eliminates total severe cold weather transfer from the exterior, which causes interior condensation.LEARN MORE
